| Varenummer | TM038QV-67A03 |
| Mærke | SANYO |
| Størrelse | 3.8 |
| Ansøgning | PDA |
| Løsning | 320×240 |
| Sammensætning | LCM |
| Lysstyrke | |
| CR | |
| Farver | 262K |
| Baggrundsbelysning | CCFL |
| Interface | TTL |
| panel mærke | TORISAN |
| panel model | TM038QV-67A03 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 3.8 inch |
| løsning | 320(RGB)×240 , QVGA |
| visningstilstand | TN, Normally White, Reflective |
| aktivt område | 76.8×57.6 mm |
| omrids | 96.8×73 mm |
| overflade | |
| lysstyrke | |
| kontrastforhold | |
| vise farver | 262K (6-bit) |
| responstid | 10/10 (Typ.)(Tr/Td) |
| synsvinkel | 60/60/50/50 (Typ.)(CR≥2)(L/R/U/D) |
| lampe type | 1 pcsCCFLWithout Driver |
| signal interface | Parallel RGB (1 ch, 6-bit), 90 pins |
| indgangsspænding | 3.3/5/14.3/-10V (Typ.)(VDD/VCC/VGH/VGL) |
| Ansøgning | PDA |
| CMD510TT00-C1 | ORTUSTECH | 3.8 | 320×240 |
| KHS038AA1AA-B70R-57-11 | Kyocera | 3.8 | 240×320 |
| LQ038Q5DR01 | SHARP | 3.8 | 320×240 |
| LQ038Q7DB03 | SHARP | 3.8 | 240×320 |
| LQ038Q7DB03A | SHARP | 3.8 | 240×320 |
| LS038Y3LX01 | SHARP | 3.8 | 480×800 |
| LS038Y7DX01 | SHARP | 3.8 | 480×800 |
| TM038QV-67A02A | SANYO | 3.8 | 320×240 |
| TM038QV-67A02E | SANYO | 3.8 | 320×240 |
| TM038QV-67A03 | SANYO | 3.8 | 320×240 |
| ACX502BMU-7 | SONY | 3.5 | 240×320 |
| LQ035Q7DH05 | SHARP | 3.5 | 240×320 |
| LTE283QV-F01 | Samsung | 2.8 | 320×240 |
| LTP500GV-F01 | Samsung | 5.0 | 480×640 |
| NL2432DR22-02B | NLT | 3.5 | 240×320 |
| NL2432HC22-22B | NLT | 3.5 | 240×320 |
| NL2432HC22-41B | NLT | 3.5 | 240×320 |
| NL4864HL11-01B | NLT | 3.5 | 480×640 |
| TD035STED4 | TPO | 3.5 | 240×320 |
| TX09D23VM1CAA | KOE | 3.5 | 240×320 |
