| Varenummer | TM121XG-02L10 |
| Mærke | SANYO |
| Størrelse | 12.1 |
| Ansøgning | NBPC |
| Løsning | 1024×768 |
| Sammensætning | LCM |
| Lysstyrke | 140 |
| CR | 300:1 |
| Farver | 262K |
| Baggrundsbelysning | CCFL |
| Interface | LVDS |
| panel mærke | TORISAN |
| panel model | TM121XG-02L10 4 Compatible model |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 12.1 inch |
| løsning | 1024(RGB)×768 , XGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 245.76×184.32 mm |
| omrids | 261×199×5.3 mm |
| overflade | Antiglare |
| lysstyrke | 140 cd/m² (Typ.) |
| kontrastforhold | 300:1 (Typ.) |
| vise farver | 262K (6-bit) |
| responstid | 32/13 (Typ.)(Tr/Td) |
| synsvinkel | 40/40/10/30 (Min.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 1 pcsCCFLWithout Driver |
| signal interface | LVDS (1 ch, 6-bit), 20 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | NBPC |
| B121EW09 V0 | AUO | 12.1 | 1280×800 |
| HV121WX4-110 | HYDIS | 12.1 | 1280×800 |
| HX121WX1-100 | HYDIS | 12.1 | 1280×800 |
| LQ121S1DG42 | SHARP | 12.1 | 800×600 |
| LT121DEVQB00 | TOSHIBA | 12.1 | 1280×800 |
| LTD121EWUD | TOSHIBA | 12.1 | 1280×800 |
| LTN121AT01-001 | Samsung | 12.1 | 1280×800 |
| LTN121XJ-L03 | Samsung | 12.1 | 1024×768 |
| TM121XG-02L01 | SANYO | 12.1 | 1024×768 |
| TM121XG-02L10 | SANYO | 12.1 | 1024×768 |
| B156HTB01.0 | AUO | 15.6 | 1920×1080 |
| B173HW02 V1 | AUO | 17.3 | 1920×1080 |
| LM130SS1T611 | SHARP | 13.0 | 800×600 |
| LP101WH1-TLP1 | LG Display | 10.1 | 1366×768 |
| LP171WX2-A4K7 | LG Display | 17.1 | 1440×900 |
| LQ106K1LA01C | SHARP | 10.6 | 1280×768 |
| LQ121X1LH22 | SHARP | 12.1 | 1024×768 |
| LTN134AT01-001 | Samsung | 13.4 | 1366×768 |
| LTN154P3-L02 | Samsung | 15.4 | 1680×1050 |
| LTN173HT02-C01 | Samsung | 17.3 | 1920×1080 |
