| Varenummer | NL10276BC20-37 |
| Mærke | NLT |
| Størrelse | 10.4 |
| Ansøgning | IA |
| Løsning | 1024×768 |
| Sammensætning | LCM |
| Lysstyrke | 150 |
| CR | 400:1 |
| Farver | 262K/16.7M |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| panel mærke | NLT |
| panel model | NL10276BC20-37 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 10.4 inch |
| løsning | 1024(RGB)×768 , XGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 210.4×157.8 mm |
| omrids | 231.2×174.6×5.8 mm |
| overflade | Clear |
| lysstyrke | 150 cd/m² (Typ.) |
| kontrastforhold | 400:1 (Typ.) |
| vise farver | 262K/16.7M (6-bit / 6-bit + Hi-FRC) |
| responstid | 3/15 (Typ.)(Tr/Td) |
| synsvinkel | 45/45/40/20 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | WLEDWithout Driver |
| signal interface | LVDS (1 ch, 6/8-bit) |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | IA |
| NL10276AC24-05 | NLT | 12.1 | 1024×768 |
| NL10276BC13-01C | NLT | 6.5 | 1024×768 |
| NL10276BC20-08 | NLT | 10.4 | 1024×768 |
| NL10276BC20-18 | NLT | 10.4 | 1024×768 |
| NL10276BC20-37 | NLT | 10.4 | 1024×768 |
| NL10276BC24-19D | NLT | 12.1 | 1024×768 |
| NL10276BC30-15 | NLT | 15.0 | 1024×768 |
| NL10276BC30-18 | NLT | 15.0 | 1024×768 |
| NL10276BC30-18C | NLT | 15.0 | 1024×768 |
| NL10276BC30-18L | NLT | 15.0 | 1024×768 |
| AM480272H3TMQW-TW2H | AMPIRE | 4.3 | 480×272 |
| CLAA102NB01XV | CPT | 10.2 | 1024×600 |
| G150XG01 V1 | AUO | 15.0 | 1024×768 |
| G220SW01 V0 | AUO | 22.0 | 1680×1050 |
| OEL9M0064-Y-E | Other | 2.0 | 128×32 |
| RGS08096032WR001 | RiTdisplay | 0.80 | 96×32 |
| RGS24128064YW005 | RiTdisplay | 2.4 | 128×64 |
| SX19V001-Z2A | KOE | 7.5 | 640×480 |
| UG-2864KLBMG01 | WiseChip | 1.54 | 128×64 |
| UG-5664ASWEF01 | WiseChip | 3.1 | 256×64 |
