| Varenummer | VVX10F011B00 |
| Mærke | Panasonic |
| Størrelse | 10.1 |
| Ansøgning | PAD |
| Løsning | 1920×1200 |
| Sammensætning | LCM |
| Lysstyrke | 650 |
| CR | 1000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | eDP |
| panel mærke | Panasonic |
| panel model | VVX10F011B00 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 10.1 inch |
| løsning | 1920(RGB)×1200 , WUXGA |
| visningstilstand | IPS, Normally Black, Transmissive |
| aktivt område | 217.44×135.9 mm |
| omrids | 228.86×152.5×4.18 mm |
| overflade | Hard coating, Antireflection |
| lysstyrke | 650 cd/m² (Min.) |
| kontrastforhold | 1000:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193150% |
| responstid | 35 (Max.)(Tr+Td) |
| synsvinkel | 80/80/80/80 (Typ.)(CR≥100)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 10S6PWLEDEmbedded (LED Driver) |
| signal interface | eDP (2 Lanes), 30 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | PAD |
