| Varenummer | TFTMD089030 |
| Mærke | JDI |
| Størrelse | 8.9 |
| Ansøgning | PAD |
| Løsning | 2560×1600 |
| Sammensætning | LCM |
| Lysstyrke | 500 |
| CR | 1200:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | MIPI |
| panel mærke | JDI |
| panel model | TFTMD089030 2 Compatible model |
| paneltype | LTPS TFT-LCD , LCM |
| panelstørrelse | 8.9 inch |
| løsning | 2560(RGB)×1600 , WQXGA |
| visningstilstand | IPS, Normally Black, Transmissive |
| aktivt område | 192×120 mm |
| omrids | 200.3×132.1×3.43 mm |
| overflade | |
| lysstyrke | 500 cd/m² (Typ.) |
| kontrastforhold | 1200:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193172% |
| responstid | |
| synsvinkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 6S6PWLEDWithout Driver |
| signal interface | MIPI (2 ch, 4 data lanes), 61 pins |
| indgangsspænding | 1.8/3.3V (Typ.)(VDDIO/VBAT) |
| Ansøgning | PAD |
| HSD089IFW1-A00 | HannStar | 8.9 | 1024×600 |
| HV089WX1-100 | HYDIS | 8.9 | 1280×768 |
| LD089WX1-SL03 | LG Display | 8.9 | 1280×768 |
| LP089WS2-TLB1 | LG Display | 8.9 | 1024×600 |
| LQ089B1LS11 | SHARP | 8.9 | 1280×600 |
| LT089AC29000 | TOSHIBA | 8.9 | 1280×768 |
| TFTMD030011 | JDI | 3.0 | 720×480 |
| TFTMD030035 | JDI | 3.0 | 640×480 |
| TFTMD070021 | JDI | 7.0 | 1200×1920 |
| TFTMD089030 | JDI | 8.9 | 2560×1600 |
| B101UAN07.2 | AUO | 10.1 | 1200×1920 |
| HJ101NA-02A | Innolux | 10.1 | 1280×800 |
| HV121WX5-113 | HYDIS | 12.1 | 1280×800 |
| HX121WX1-111 | HYDIS | 12.1 | 1280×800 |
| LP116WH4-SLN1 | LG Display | 11.6 | 1366×768 |
| LTL089CL02-001 | Samsung | 8.9 | 1920×1200 |
| LTN097QL01-A01 | Samsung | 9.7 | 2048×1536 |
| NDS0708001280-31 | SEBO | 7.0 | 800×1280 |
| TM080TDHG01 | Tianma | 8.0 | 1024×768 |
| YX101GL-01A | SEBO | 10.1 | 1280×800 |
