| Varenummer | 24QVF2H |
| Mærke | SII |
| Størrelse | 2.4 |
| Ansøgning | HHP |
| Løsning | 240×320 |
| Sammensætning | LCM |
| Lysstyrke | 300 |
| CR | 800:1 |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | TTL |
| panel mærke | SII |
| panel model | 24QVF2H |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 2.4 inch |
| løsning | 240(RGB)×320 , QVGA |
| visningstilstand | IPS, Normally Black, Transmissive |
| aktivt område | 36.72×48.96 mm |
| omrids | 42.72×60.4 mm |
| overflade | Clear, Hard coating |
| lysstyrke | 300 cd/m² (Typ.) |
| kontrastforhold | 800:1 (Typ.) |
| vise farver | 262K (6-bit), CIE193172% |
| responstid | 35 (Typ.)(Tr+Td) |
| synsvinkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| lampe type | 4S1PWLED |
| signal interface | Parallel RGB (1 ch, 6-bit) + SPI, 35 pins |
| indgangsspænding | (1.65~3.3)/(2.5~3.3)(IOVCC/VCI) |
| Ansøgning | HHP |
