| Varenummer | COM24H2N62XLC |
| Mærke | ORTUSTECH |
| Størrelse | 2.4 |
| Ansøgning | HHP |
| Løsning | 240×320 |
| Sammensætning | LCM |
| Lysstyrke | 300 |
| CR | 400:1 |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | TTL |
| panel mærke | ORTUSTECH |
| panel model | COM24H2N62XLC 1 Compatible model |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 2.4 inch |
| løsning | 240(RGB)×320 , QVGA |
| visningstilstand | TN, Normally White, Transflective |
| aktivt område | 36×48 mm |
| omrids | 42.5×58.5×4 mm |
| overflade | Hard coating (3H) |
| lysstyrke | 300 cd/m² (Typ.) |
| kontrastforhold | 400:1 (Typ.)(Transmissive)8.5:1 (Typ.)(Reflective) |
| vise farver | 262K (6-bit) |
| responstid | 40/60 (Max.)(Tr/Td) |
| synsvinkel | 80/80/80/80 (Min.)(CR≥10)(L/R/U/D) |
| lampe type | 2S1PWLEDWithout Driver |
| signal interface | Parallel RGB (1 ch, 6-bit), 39 pins |
| indgangsspænding | 3.0V (Typ.) |
| Ansøgning | HHP |
