| Varenummer | 32WQF0H |
| Mærke | SII |
| Størrelse | 3.2 |
| Ansøgning | HHP |
| Løsning | 240×400 |
| Sammensætning | LCM |
| Lysstyrke | 450 |
| CR | 800:1 |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | TTL |
| panel mærke | SII |
| panel model | 32WQF0H |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 3.2 inch |
| løsning | 240(RGB)×400 , WQVGA |
| visningstilstand | FFS, Normally Black, Transmissive |
| aktivt område | 41.76×69.6 mm |
| omrids | 47.66×82.1 mm |
| overflade | Clear, Hard coating |
| lysstyrke | 450 cd/m² (Typ.) |
| kontrastforhold | 800:1 (Typ.) |
| vise farver | 262K (6-bit), CIE193168% |
| responstid | 35 (Typ.)(Tr+Td) |
| synsvinkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| lampe type | 6S1PWLED |
| signal interface | Parallel RGB, 51 pins |
| Ansøgning | HHP |
