| Varenummer | DLC0090AZG |
| Mærke | Other |
| Størrelse | 0.91 |
| Ansøgning | HHP |
| Løsning | 80×160 |
| Sammensætning | LCM |
| Lysstyrke | 100 |
| CR | 500:1 |
| Farver | |
| Baggrundsbelysning | WLED |
| Interface | SPI |
| panel mærke | DLC |
| panel model | DLC0090AZG |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 0.91 inch |
| løsning | 80(RGB)×160 |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 11.52×20.16 mm |
| omrids | 15.8×27×1.81 mm |
| overflade | |
| lysstyrke | 100 cd/m² (Typ.) |
| kontrastforhold | 500:1 (Typ.) |
| vise farver | , CIE193138% |
| responstid | 10/10 (Typ.)(Tr/Td) |
| synsvinkel | 45/45/35/45 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 1 pcsWLEDWithout Driver |
| signal interface | 4-wire SPI, 33 pins |
| indgangsspænding | 2.8V (Typ.) |
| Ansøgning | HHP |
