| Varenummer | T-55343GD035JU-LW-AFN |
| Mærke | Kyocera |
| Størrelse | 3.5 |
| Ansøgning | HHP |
| Løsning | 320×240 |
| Sammensætning | LCM |
| Lysstyrke | 360 |
| CR | 700:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | TTL |
| panel mærke | OPTREX |
| panel model | T-55343GD035JU-LW-AFN |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 3.5 inch |
| løsning | 320(RGB)×240 , QVGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 70.08×52.56 mm |
| omrids | 79×65×4.2 mm |
| overflade | Antiglare |
| lysstyrke | 360 cd/m² (Typ.) |
| kontrastforhold | 700:1 (Typ.) |
| vise farver | 16.7M (8-bit) |
| responstid | 8/15 (Typ.)(Tr/Td) |
| synsvinkel | 80/80/80/80 (Typ.)(CR≥5)(L/R/U/D) |
| lampe type | 6S1PWLEDWithout Driver |
| signal interface | Parallel RGB (1 ch, 8-bit) + SPI, 40 pins |
| indgangsspænding | 3.3V (Typ.)(VCC) |
| Ansøgning | HHP |
| A035QN01 V4 | AUO | 3.5 | 320×240 |
| ACX565AKM-7 | SONY | 3.5 | 800×480 |
| COM35H3M74UTC | ORTUSTECH | 3.5 | 480×640 |
| ET035009DH6 | EDT | 3.5 | 320×240 |
| LH350H01-FD01-A41 | LG Display | 3.5 | 320×480 |
| NL2432DR22-11B | NLT | 3.5 | 240×320 |
| PD035VX8 | E Ink | 3.5 | 480×640 |
| PW035XU1 | E Ink | 3.5 | 320×234 |
| T-55343GD035JU-LW-AFN | Kyocera | 3.5 | 320×240 |
| TD035STEB2 | TPO | 3.5 | 240×320 |
| 20QVF0H | SII | 2.0 | 240×320 |
| 28QVF2J | SII | 2.8 | 240×320 |
| AM-240320-022F | Other | 2.2 | 240×320 |
| COM32H3N74ULC | ORTUSTECH | 3.2 | 480×800 |
| LQ035Q3DG02A | SHARP | 3.5 | 320×240 |
| LQ038Q7DB03R | SHARP | 3.8 | 240×320 |
| LQ040Y3DX80 | SHARP | 4.0 | 480×800 |
| T-51963GD035J-MLW-AJN | Kyocera | 3.5 | 240×320 |
| TM030LDHT1 | Tianma | 3.0 | 240×400 |
| TM035HDHT1 | Tianma | 3.5 | 240×320 |
