| Varenummer | 35WVF0H |
| Mærke | SII |
| Størrelse | 3.5 |
| Ansøgning | HHP |
| Løsning | 480×800 |
| Sammensætning | LCM |
| Lysstyrke | 300 |
| CR | 800:1 |
| Farver | 16.2M |
| Baggrundsbelysning | WLED |
| Interface | TTL |
| panel mærke | SII |
| panel model | 35WVF0H |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 3.5 inch |
| løsning | 480(RGB)×800 , WVGA |
| visningstilstand | FFS, Normally Black, Transmissive |
| aktivt område | 45.36×75.6 mm |
| omrids | 51.46×90.55 mm |
| overflade | Clear, Hard coating |
| lysstyrke | 300 cd/m² (Typ.) |
| kontrastforhold | 800:1 (Typ.) |
| vise farver | 16.2M (6-bit + Dithering), CIE193170% |
| responstid | 35 (Typ.)(Tr+Td) |
| synsvinkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| lampe type | 6S1PWLED |
| signal interface | Parallel RGB (1 ch, 6/8-bit) + SPI, 61 pins |
| Ansøgning | HHP |
| 35WVF0H | SII | 3.5 | 480×800 |
| 35WVF1H | SII | 3.5 | 480×800 |
| ELT160.80.50 | Lumineq | 3.5 | 160×80 |
| LB035Q01-TJ01 | LG Display | 3.5 | 320×240 |
| LQ035JC211 | Innolux | 3.5 | 320×240 |
| LQ035Q7DB03F | SHARP | 3.5 | 240×320 |
| LTV350QV-F05 | Samsung | 3.5 | 320×240 |
| NL2432HC22-22B | NLT | 3.5 | 240×320 |
| NL2432HC22-32B | NLT | 3.5 | 240×320 |
| NL4864HL11-01B | NLT | 3.5 | 480×640 |
| 28QVF1H | SII | 2.8 | 240×320 |
| 32NHF0H | SII | 3.2 | 360×640 |
| COM24H2N62XLC | ORTUSTECH | 2.4 | 240×320 |
| COM35H3P09UTC | ORTUSTECH | 3.5 | 480×640 |
| DLC0430NZG | Other | 4.3 | 480×272 |
| LQ043T1DG03B | SHARP | 4.3 | 480×272 |
| LS024Q3UX12(G) | SHARP | 2.4 | 320×240 |
| LS027B7DH01 | SHARP | 2.7 | 400×240 |
| PD035VX9 | E Ink | 3.5 | 480×640 |
| TFTMD030011 | JDI | 3.0 | 720×480 |
