| Varenummer | TFTMD030011 |
| Mærke | JDI |
| Størrelse | 3.0 |
| Ansøgning | HHP |
| Løsning | 720×480 |
| Sammensætning | LCM |
| Lysstyrke | 500 |
| CR | 500:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | YUV |
| panel mærke | JDI |
| panel model | TFTMD030011 |
| paneltype | LTPS TFT-LCD , LCM |
| panelstørrelse | 3.0 inch |
| løsning | 720(RGB)×480 |
| visningstilstand | IPS, Normally Black, Transmissive |
| aktivt område | 63.72×42.48 mm |
| omrids | 72.88×53.16 mm |
| overflade | Hard coating |
| lysstyrke | 500 cd/m² (Typ.) |
| kontrastforhold | 500:1 (Typ.) |
| vise farver | 16.7M (8-bit), sRGB100% |
| responstid | 30/30 (Typ.)(Tr/Td) |
| synsvinkel | 80/80/80/80 (Typ.)(CR≥100)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | WLEDWithout Driver |
| signal interface | YUV (8-bit), 51 pins |
| indgangsspænding | 1.8/3.0V (Typ.)(VDDIO/VDD) |
| Ansøgning | HHP |
