| Varenummer | 990000006 |
| Mærke | TPO |
| Størrelse | 3.0 |
| Ansøgning | DSC |
| Løsning | 320×240 |
| Sammensætning | LCM |
| Lysstyrke | 250 |
| CR | 400:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | Serial RGB |
| panel mærke | TPO |
| panel model | 990000006 |
| paneltype | LTPS TFT-LCD , LCM |
| panelstørrelse | 3.0 inch |
| løsning | 320(RGB)×240 , QVGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 65.31×36.84 mm |
| omrids | 75.31×43.44 mm |
| overflade | Hard coating (3H) |
| lysstyrke | 250 cd/m² (Typ.) |
| kontrastforhold | 400:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193140% |
| responstid | 5/11 (Typ.)(Tr/Td) |
| synsvinkel | 60/60/50/60 (Min.)(CR≥10)(L/R/U/D) |
| lampe type | 3S1PWLEDWithout Driver |
| signal interface | Serial RGB (8-bit) + SPI, 39 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | DSC |
