| Varenummer | 990000475 |
| Mærke | TPO |
| Størrelse | 4.3 |
| Ansøgning | PND |
| Løsning | 800×480 |
| Sammensætning | LCM |
| Lysstyrke | 300 |
| CR | 400:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | TTL |
| panel mærke | TPO |
| panel model | 990000475 |
| paneltype | LTPS TFT-LCD , LCM |
| panelstørrelse | 4.3 inch |
| løsning | 800(RGB)×480 , WVGA |
| visningstilstand | Normally Black, Transmissive |
| aktivt område | 93.6×56.16 mm |
| omrids | 100.6×68.45 mm |
| overflade | |
| lysstyrke | 300 cd/m² (Typ.) |
| kontrastforhold | 400:1 (Typ.) |
| vise farver | 16.7M (8-bit) |
| responstid | 30/10 (Typ.)(Tr/Td) |
| synsvinkel | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| lampe type | 8S1PWLEDWithout Driver |
| signal interface | Parallel RGB (1 ch, 8-bit) + SPI, 60 pins |
| indgangsspænding | 3.3/5/-5V (Typ.)(VCC/AVDP/AVDN) |
| Ansøgning | PND |
| 990000006 | TPO | 3.0 | 320×240 |
| 990000270 | TPO | 2.5 | 320×240 |
| 990000475 | TPO | 4.3 | 800×480 |
| 990000475P | TPO | 4.3 | 800×480 |
| 990000553 | TPO | 3.5 | 320×240 |
| 990000738 | TPO | 3.5 | 320×240 |
| 990000738A | Innolux | 3.5 | 320×240 |
| 990000881 | TPO | 3.0 | 960×480(dot) |
| 990001086 | Innolux | 3.0 | |
| DLC0430NZG | Other | 4.3 | 480×272 |
| 43WQW3T | SII | 4.3 | 480×272 |
| 43WVF0H | SII | 4.3 | 800×480 |
| A050FW02 V5 | AUO | 5.0 | 480×272 |
| AT050TN33 | Innolux | 5.0 | 480×272 |
| CLAA050LA0ACW | CPT | 5.0 | 800×480 |
| EJ050NA-01G | Innolux | 5.0 | 800×480 |
| LQ043T3DX04 | SHARP | 4.3 | 480×272 |
| P0430WQLC-T | CMEL | 4.3 | 480×272 |
| PT035TN01 V.3 | Innolux | 3.5 | 320×240 |
| TM047NBH01 | Tianma | 4.7 | 480×272 |
