| Varenummer | GCX123AKQ-E |
| Mærke | JDI |
| Størrelse | 3.5 |
| Ansøgning | CNS |
| Løsning | 240×320 |
| Sammensætning | LCM |
| Lysstyrke | 620 |
| CR | 900:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | TTL |
| panel mærke | JDI |
| panel model | GCX123AKQ-E |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 3.5 inch |
| løsning | 240(RGB)×320 , QVGA |
| visningstilstand | IPS, Normally Black, Transmissive |
| aktivt område | 53.28×71.04 mm |
| omrids | 81.6×95.57×25.3 mm |
| overflade | |
| lysstyrke | 620 cd/m² (Typ.) |
| kontrastforhold | 900:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193165% |
| responstid | 53 (Max.)(Tr+Td) |
| synsvinkel | |
| frekvens | 60Hz |
| lampe type | 2S2PWLEDWithout Driver |
| signal interface | Parallel RGB (1 ch, 8-bit) + SPI, 50 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | CNS |
| AMS347FF01 | Samsung | 3.5 | 360×640 |
| GCX123AKQ-E | JDI | 3.5 | 240×320 |
| H347QVN02.0 | AUO | 3.5 | 320×480 |
| LB035Q03-TD02 | LG Display | 3.5 | 320×240 |
| LH350WS1-SH02 | LG Display | 3.5 | 640×960 |
| LQ035Q1DG02 | SHARP | 3.5 | 320×240 |
| LQ035Q3DG02A | SHARP | 3.5 | 320×240 |
| LTV035QV-F04 | Samsung | 3.5 | 320×240 |
| LTV350QV-F05 | Samsung | 3.5 | 320×240 |
| LTV350QV-F09 | Samsung | 3.5 | 320×240 |
| AV080WSM-NW3 | BOE | 8.0 | 1024×600 |
| C030DW01 V0 | AUO | 3.0 | 320×240 |
| C070VW04 V2 | AUO | 7.0 | 800×480 |
| CLAA070LFA1 CW | CPT | 7.0 | 800×480 |
| HSD070IDW1-D00 | HannStar | 7.0 | 800×480 |
| L5F30947T0A | Epson | 6.5 | 800×480 |
| LA061WQ1-TD04 | LG Display | 6.1 | 480×272 |
| LB040Q02-TD05 | LG Display | 4.0 | 320×240 |
| LB043WQ4-TD01 | LG Display | 4.3 | 480×272 |
| M050SWN1 R2 | IVO | 5.0 | 480×234 |
