| Varenummer | PA080XS2 |
| Mærke | E Ink |
| Størrelse | 7.9 |
| Ansøgning | CNS |
| Løsning | 480×468 |
| Sammensætning | LCM |
| Lysstyrke | 350 |
| CR | 350:1 |
| Farver | Full color |
| Baggrundsbelysning | CCFL |
| Interface | Analog |
| panel mærke | PVI |
| panel model | PA080XS2 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 7.9 inch |
| løsning | 480(RGB)×468 |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 161.28×117.936 mm |
| omrids | 172.4×132×6.9 mm |
| overflade | Antiglare |
| lysstyrke | 350 cd/m² (Typ.) |
| kontrastforhold | 350:1 (Typ.) |
| vise farver | Full color |
| responstid | 15/25 (Typ.)(Tr/Td) |
| synsvinkel | 60/60/40/50 (Typ.)(CR≥10)(L/R/U/D) |
| lampe type | 1 pcsCCFLWithout Driver |
| signal interface | TFT Specific Analog RGB, 32 pins |
| indgangsspænding | 3.3/3.3/13.0/24.0/-8.0V (Typ.)(VCC/VDD1/VDD2/VGH/VEE) |
| Ansøgning | CNS |
| A070VTN03.0 | AUO | 7.0 | 800×480 |
| AM-800480RSTMQW-TA1H | AMPIRE | 7.0 | 800×480 |
| C070VW03 V0 | AUO | 7.0 | 800×480 |
| C123HAN01.0 | AUO | 12.3 | 1920×720 |
| DLC1040ABG-T-2 | Other | 10.4 | 800×600 |
| HSD070IFW1-A00 | HannStar | 7.0 | 1024×600 |
| LA080WV8-SL01 | LG Display | 8.0 | 800×480 |
| LQ065T9BR51U | SHARP | 6.5 | 400×240 |
| TD070WGCB2 | TPO | 7.0 | 854×480 |
| TFD65W46 | TOSHIBA | 6.5 | 480×234 |
