| Varenummer | ACX435AKN-7 |
| Mærke | SONY |
| Størrelse | 4.5 |
| Ansøgning | MPH |
| Løsning | 800×1280 |
| Sammensætning | LCM |
| Lysstyrke | 550 |
| CR | 900:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | MIPI |
| panel mærke | SONY |
| panel model | ACX435AKN-7 |
| paneltype | LTPS TFT-LCD , LCM |
| panelstørrelse | 4.5 inch |
| løsning | 800(RGB)×1280 , WXGA |
| visningstilstand | Vistarich, Normally Black, Transmissive |
| aktivt område | 60.6×96.96 mm |
| omrids | 64.4×106.95 mm |
| overflade | Clear, Hard coating (2H) |
| lysstyrke | 550 cd/m² (Typ.) |
| kontrastforhold | 900:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193155% |
| responstid | 25/20 (Typ.)(Tr/Td) |
| synsvinkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 10S1PWLEDWithout Driver |
| signal interface | MIPI (4 data lanes), 30 pins |
| indgangsspænding | 5.6/1.8V (Typ.) |
| Ansøgning | MPH |
