| Varenummer | CLAF050LG41 TXX |
| Mærke | CPT |
| Størrelse | 5.0 |
| Ansøgning | MPH |
| Løsning | 540×960 |
| Sammensætning | CELL |
| Lysstyrke | 0 |
| CR | 500:1 |
| Farver | |
| Baggrundsbelysning | No B/L |
| Interface | |
| panel mærke | CPT |
| panel model | CLAF050LG41 TXX 4 Compatible model |
| paneltype | a-Si TFT-LCD , CELL |
| panelstørrelse | 5.0 inch |
| løsning | 540(RGB)×960 , qHD |
| visningstilstand | HFFS, Normally Black, Transmissive |
| aktivt område | 61.965×110.16 mm |
| omrids | 64.87×118.31×0.4 mm |
| overflade | Without Polarizer |
| glas dybde | 0.20+0.20 mm |
| transmissivitet | 3.74% (Typ.)(with Polarizer) |
| kontrastforhold | 500:1 (Typ.) |
| vise farver | , CIE193170% |
| responstid | 30 (Typ.)(Tr+Td) |
| synsvinkel | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| driver ic | Suggest NT35516, OTM9608, OTM9605 |
| Ansøgning | MPH |
