| Varenummer | TM035PDH53 |
| Mærke | Tianma |
| Størrelse | 3.5 |
| Ansøgning | MPH |
| Løsning | 320×480 |
| Sammensætning | LCM |
| Lysstyrke | 300 |
| CR | 500:1 |
| Farver | 65K/262K |
| Baggrundsbelysning | WLED |
| Interface | CPU/RGB |
| panel mærke | TIANMA |
| panel model | TM035PDH53 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 3.5 inch |
| løsning | 320(RGB)×480 , HVGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 48.96×73.44 mm |
| omrids | 54.34×84.07×2.1 mm |
| overflade | Clear |
| lysstyrke | 300 cd/m² (Typ.) |
| kontrastforhold | 500:1 (Typ.) |
| vise farver | 65K/262K , CIE193160% |
| responstid | 20 (Typ.)(Tr+Td) |
| synsvinkel | 70/70/70/60 (Typ.)(CR≥10)(L/R/U/D) |
| lampe type | 6S1PWLEDWithout Driver |
| signal interface | CPU/RGB, 45 pins |
| indgangsspænding | 1.8/2.8 (Typ.)(IOVCC/VCC) |
| Ansøgning | MPH |
| TM035KBH02 | Tianma | 3.5 | 320×240 |
| TM035KDH03 | Tianma | 3.5 | 320×240 |
| TM035KDH04 | Tianma | 3.5 | 320×240 |
| TM035KDH05 | Tianma | 3.5 | 320×240 |
| TM035KDH08 | Tianma | 3.5 | 320×240 |
| TM035KDH16-09 | Tianma | 3.5 | 320×240 |
| TM035NDH04 | Tianma | 3.5 | 272×480 |
| TM035PDH53 | Tianma | 3.5 | 320×480 |
| TM035PDZ15 | Tianma | 3.5 | 320×480 |
| TM035WBHG01 | Tianma | 3.5 | 480×640 |
| AMEJ006 | Samsung | 2.8 | 240×400 |
| AMS320FS03 | Samsung | 3.2 | 320×480 |
| BA060WV1-100 CELL | BOE | 6.0 | 480×854 |
| DLC0283FZG-7 | Other | 2.8 | 240×320 |
| H497TLB01 | AUO | 5.0 | 720×1280 |
| LH240Q29-SH04 | LG Display | 2.4 | 240×320 |
| LT032MDQ7000 | JDI | 3.2 | 360×480 |
| PJ035MA-02A | Innolux | 3.5 | 320×480 |
| TM020GDZ25 | Tianma | 2.0 | 176×220 |
| TM028HDH21 | Tianma | 2.8 | 240×320 |
