| Varenummer | G043FTT01.0 |
| Mærke | AUO |
| Størrelse | 4.3 |
| Ansøgning | HHP |
| Løsning | 480×272 |
| Sammensætning | LCM |
| Lysstyrke | 400 |
| CR | 400:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | TTL |
| panel mærke | AUO |
| panel model | G043FTT01.0 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 4.3 inch |
| løsning | 480(RGB)×272 , WQVGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 95.04×53.856 mm |
| omrids | 105.5×67.2 mm |
| overflade | Antiglare (Haze 8%), Hard coating (3H) |
| lysstyrke | 400 cd/m² (Typ.) |
| kontrastforhold | 400:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193150% |
| responstid | 15/20 (Typ.)(Tr/Td) |
| synsvinkel | 65/65/50/55 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 9S1PWLEDWithout Driver |
| signal interface | Parallel RGB (1 ch, 8-bit), 45 pins |
| indgangsspænding | 3.3/3.3V (Typ.)(VDD/VDDIO) |
| Ansøgning | HHP |
| AM480272H3TMQW-W2H | AMPIRE | 4.3 | 480×272 |
| AMS429QC08 | Samsung | 4.3 | 540×960 |
| DLC0430EZG-11 | Other | 4.3 | 480×272 |
| G043FTT01.0 | AUO | 4.3 | 480×272 |
| G043FW01 V0 | AUO | 4.3 | 480×272 |
| H430VL02 V4 | AUO | 4.3 | 480×800 |
| LB043WQ1-TD01 | LG Display | 4.3 | 480×272 |
| LH430WV1-SD01 | LG Display | 4.3 | 480×800 |
| LQ043T3DG02 | SHARP | 4.3 | 480×272 |
| LQ043Y1DX02 | SHARP | 4.3 | 480×800 |
| 24QVW2H | SII | 2.4 | 240×320 |
| 30WQF0H | SII | 3.0 | 240×400 |
| 35WVF0H | SII | 3.5 | 480×800 |
| COM24H2N62XLC | ORTUSTECH | 2.4 | 240×320 |
| COM35H3M10XTC | ORTUSTECH | 3.5 | 240×320 |
| DLC0240ACOG-3 | Other | 2.4 | 240×320 |
| LQ035Q3DG01 | SHARP | 3.5 | 320×240 |
| LQ035Q7DB03F | SHARP | 3.5 | 240×320 |
| LQ043T1DG28 | SHARP | 4.3 | 480×272 |
| TX09D30VM1CCA | KOE | 3.5 | 240×320 |
