| Varenummer | AM-320240LQTZQW-50H |
| Mærke | AMPIRE |
| Størrelse | 3.5 |
| Ansøgning | Industrial Outdoor H |
| Løsning | 320×240 |
| Sammensætning | a-Si TFT-LCD , LCM |
| Lysstyrke | |
| CR | 1000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | 6S2P |
| Interface | Parallel |
| panel mærke | AMPIRE |
| panelstørrelse | 3.5" |
| løsning | 320(RGB)×240, QVGA, 115PPI |
| udstillingsområde | 70.08(W)×52.56(H) mm |
| konturstørrelse | 76.9(W)×63.9(H) ×3.45(D) mm |
| lysstyrke | 800 cd/m² (Typ.) |
| synsvinkel | 85/85/85/85 (Typ.)(CR≥10) |
| bedste udsigt på | Symmetry |
| vise farver | 16.7M 60% NTSC |
| frekvens | 60Hz |
| panelvægt | - |
| signal interface | Parallel RGB (1 ch, 8-bit) + SPI , 50 pins FPC |
| indgangsspænding | 3.3V (Typ.) |
| miljø | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
| panel model | AM-320240LQTZQW-50H |
| paneltype | a-Si TFT-LCD , LCM |
| pixel format | RGB Vertical Stripe |
| bezel åbning | 72.88(W)×54.94(H) mm |
| overflade | - |
| kontrastforhold | 1000:1 (Typ.) (TM) |
| visningstilstand | Normally Black, Transmissive |
| responstid | 30 (Typ.)(Tr+Td) |
| lampe type | 6S2P WLED , 36K hours , Without Driver |
| berøringsskærm | Without |
| Ansøgning | Industrial Outdoor High Brightness Instruments & Meters |
