| Varenummer | CLAA035JA01CW |
| Mærke | CPT |
| Størrelse | 3.5 |
| Ansøgning | |
| Løsning | 144×480 |
| Sammensætning | LCM |
| Lysstyrke | 300 |
| CR | 500:1 |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | TTL |
| panel mærke | CPT |
| panel model | CLAA035JA01CW |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 3.5 inch |
| løsning | 144(RGB)×480 |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 25.92×86.4 mm |
| omrids | 33.9×100.2 mm |
| overflade | Antiglare |
| lysstyrke | 300 cd/m² (Typ.) |
| kontrastforhold | 500:1 (Typ.) |
| vise farver | 262K (6-bit), CIE193150% |
| responstid | 25 (Typ.)(Tr+Td) |
| synsvinkel | 70/70/50/70 (Typ.)(CR≥10)(L/R/U/D) |
| lampe type | 2S2PWLEDWithout Driver |
| signal interface | Parallel RGB (1 ch, 6-bit) + SPI, 67 pins |
| indgangsspænding | 2.8/2.8/2.8V (Typ.)(VCC/VCI/IOVCC) |
| rohs: |
