| Varenummer | AM-800480RSTMQW-TBCH |
| Mærke | AMPIRE |
| Størrelse | 7.0 |
| Ansøgning | Industrial |
| Løsning | 800×480 |
| Sammensætning | a-Si TFT-LCD, LCM |
| Lysstyrke | |
| CR | 400:1 |
| Farver | 262K |
| Baggrundsbelysning | 3S10P |
| Interface | LVDS |
| panel mærke | AMPIRE |
| panel model | AM-800480RSTMQW-TBCH |
| panelstørrelse | 7.0" |
| paneltype | a-Si TFT-LCD, LCM |
| løsning | 800(RGB)×480, WVGA, 133PPI |
| pixel format | RGB Vertical Stripe |
| udstillingsområde | 152.4(W)×91.44(H) mm |
| bezel åbning | 155.3(W)×94.3(H) mm |
| konturstørrelse | 174(W)×118(H) ×11.99(D) mm |
| overflade | - |
| lysstyrke | 425 cd/m² (Typ.) |
| kontrastforhold | 400:1 (Typ.) (TM) |
| synsvinkel | 70/70/70/60 (Typ.)(CR≥10) |
| visningstilstand | TN, Normally White, Transmissive |
| bedste udsigt på | 6 o'clock |
| responstid | 5/11 (Typ.)(Tr/Td) |
| vise farver | 262K |
| lampe type | 3S10P WLED , 40K hours , With LED Driver |
| frekvens | 60Hz |
| berøringsskærm | PCAP |
| panelvægt | TBD |
| Ansøgning | Industrial |
| signal interface | LVDS (1 ch, 6-bit) , 40 pins Connector |
| indgangsspænding | 3.3V (Typ.) |
| miljø | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
