| Varenummer | AM480272H3TMQW-W2H |
| Mærke | AMPIRE |
| Størrelse | 4.3 |
| Ansøgning | IA |
| Løsning | 480×272 |
| Sammensætning | LCM |
| Lysstyrke | 500 |
| CR | 250:1 |
| Farver | 65K/262K |
| Baggrundsbelysning | WLED |
| Interface | CPU |
| panel mærke | AMPIRE |
| panel model | AM480272H3TMQW-W2H |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 4.3 inch |
| løsning | 480(RGB)×272 , WQVGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 95.04×53.856 mm |
| omrids | 105.5×67.2×6.9 mm |
| overflade | |
| lysstyrke | 500 cd/m² (Typ.) |
| kontrastforhold | 250:1 (Typ.) |
| vise farver | 65K/262K , CIE193152% |
| responstid | 15/35 (Typ.)(Tr/Td) |
| synsvinkel | 70/70/35/55 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 7S1PWLEDWithout Driver |
| signal interface | 8/9/16/18-bit 6800/8080 parallel, 40 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | IA |
| 43WQW3H | SII | 4.3 | 480×272 |
| A043FW02 V8 | AUO | 4.3 | 480×272 |
| AM480272H3TMQW-T00H | AMPIRE | 4.3 | 480×272 |
| AM480272H3TMQW-TW2H | AMPIRE | 4.3 | 480×272 |
| AM480272H3TMQW-W2H | AMPIRE | 4.3 | 480×272 |
| G043FW01 V0 | AUO | 4.3 | 480×272 |
| LB043WQ3-TD01 | LG Display | 4.3 | 480×272 |
| LMS430HF19 | Samsung | 4.3 | 480×272 |
| LR430RC9601 | Innolux | 4.3 | 480×272 |
| LTE430WQ-F0B | Samsung | 4.3 | 480×272 |
| DMF-50840NB-FW | Kyocera | 5.7 | 320×240 |
| G104SN03 V0 | AUO | 10.4 | 800×600 |
| KCB104VG2CG-G20 | Kyocera | 10.4 | 640×480 |
| KCS072VG1MF-G40 | Kyocera | 7.2 | 640×480 |
| LB121S1-A2 | LG Display | 12.1 | 800×600 |
| LM32010P | SHARP | 4.7 | 320×240 |
| NL4823BC37-05 | NLT | 7.0 | 480×234 |
| TM104SBH01 | Tianma | 10.4 | 800×600 |
| TX31D41VM2BAA | KOE | 12.1 | 800×600 |
| UG-2864KLBMG01 | WiseChip | 1.54 | 128×64 |
