| Varenummer | AM480272H3TMQW-TW2H |
| Mærke | AMPIRE |
| Størrelse | 4.3 |
| Ansøgning | IA |
| Løsning | 480×272 |
| Sammensætning | LCM |
| Lysstyrke | 400 |
| CR | 250:1 |
| Farver | 65K/262K |
| Baggrundsbelysning | WLED |
| Interface | CPU |
| panel mærke | AMPIRE |
| panel model | AM480272H3TMQW-TW2H |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 4.3 inch |
| løsning | 480(RGB)×272 , WQVGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 95.04×53.856 mm |
| omrids | 105.5×67.2×7.91 mm |
| overflade | |
| lysstyrke | 400 cd/m² (Typ.) |
| kontrastforhold | 250:1 (Typ.) |
| vise farver | 65K/262K |
| responstid | 15/35 (Typ.)(Tr/Td) |
| synsvinkel | 70/70/35/55 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 7S1PWLEDWithout Driver |
| signal interface | 8/9/16/18-bit 6800/8080 parallel, 40 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | IA |
