| Varenummer | AMCB004 |
| Mærke | Samsung |
| Størrelse | 2.4 |
| Ansøgning | MPH |
| Løsning | 240×320 |
| Sammensætning | OLED |
| Lysstyrke | 200 |
| CR | 30000:1 |
| Farver | 262K |
| Baggrundsbelysning | self |
| Interface | CPU |
| panel mærke | SAMSUNG SDI |
| panel model | AMCB004 |
| paneltype | AM-OLED , OLED |
| panelstørrelse | 2.4 inch |
| løsning | 240(RGB)×320 , QVGA |
| aktivt område | 36.72×48.96 mm |
| omrids | 42.32×58.42 mm |
| overflade | Antiglare, Hard coating (2H) |
| lysstyrke | 200 cd/m² (Typ.) |
| kontrastforhold | 30000 : 1 (Typ.) |
| vise farver | 262K (6-bit), CIE1931106% |
| synsvinkel | 90/90/90/90 (Max.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| signal interface | CPU, 31 pins |
| indgangsspænding | 3.0/3.8V (Typ.)(VDD/Vbat) |
| Ansøgning | MPH |
