| Varenummer | BB050HDG-T40 |
| Mærke | BOE |
| Størrelse | 5.0 |
| Ansøgning | MPH |
| Løsning | 720×1280 |
| Sammensætning | OLED |
| Lysstyrke | 350 |
| CR | 17000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | self |
| Interface | MIPI |
| panel mærke | BOE |
| panel model | BB050HDG-T40 |
| paneltype | AM-OLED , OLED |
| panelstørrelse | 5.0 inch |
| løsning | 720(RGB)×1280 , WXGA |
| aktivt område | 61.92×110.08 mm |
| omrids | 64.12×116.72 mm |
| overflade | Hard coating |
| lysstyrke | 350 cd/m² (Typ.) |
| kontrastforhold | 17000 : 1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE1931101% |
| synsvinkel | 80/80/80/80 (Min.)(L/R/U/D) |
| frekvens | 60Hz |
| driver ic | COG Built-in RM67120 |
| signal interface | MIPI (4 data lanes) |
| indgangsspænding | 2.8/1.8/6.0V (Typ.)(VCI/VDDIO/AVDD) |
| Ansøgning | MPH |
| AM-800480LTMQW-00H-F | AMPIRE | 5.0 | 800×480 |
| AMS495QA01 | Samsung | 5.0 | 960×544 |
| BB050HDG-T40 | BOE | 5.0 | 720×1280 |
| EJ050NA-01D | Innolux | 5.0 | 800×480 |
| LQ050T5DG01 | SHARP | 5.0 | 400×240 |
| LTG500QV-F03 | Samsung | 5.0 | 320×240 |
| LTP500GV-F01 | Samsung | 5.0 | 480×640 |
| PD050OX1 | E Ink | 5.0 | 480×480 |
| PD050VX2 | E Ink | 5.0 | 480×640 |
| TFD50W32-B2 | TOSHIBA | 5.0 |
| ACX565AKM-7 | SONY | 3.5 | 800×480 |
| AMS347FF01 | Samsung | 3.5 | 360×640 |
| CLAN050LL31 1XG | CPT | 5.0 | 480×800 |
| LH350WS1-SH02 | LG Display | 3.5 | 640×960 |
| LM18WGSBZ05 | SHARP | 1.8 | 120×160 |
| LMS283GF11 | Samsung | 2.8 | 240×320 |
| LS055T3SX05 | SHARP | 5.5 | 1080×1920 |
| LTP280QV-E01 | Samsung | 2.8 | 240×320 |
| TM020GDZ25 | Tianma | 2.0 | 176×220 |
| TM020HDZ05 | Tianma | 2.0 | 240×320 |
