| Varenummer | LQ043T1LX01A |
| Mærke | SHARP |
| Størrelse | 4.3 |
| Ansøgning | MPH |
| Løsning | 540×960 |
| Sammensætning | LCM |
| Lysstyrke | 500 |
| CR | 1000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | MDDI/MIPI |
| panel mærke | SHARP |
| panel model | LQ043T1LX01A |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 4.3 inch |
| løsning | 540(RGB)×960 , qHD |
| visningstilstand | ASV, Normally Black, Transmissive |
| aktivt område | 53.46×95.04 mm |
| omrids | 58.54×105.7 mm |
| overflade | Hard coating (3H) |
| lysstyrke | 500 cd/m² (Typ.) |
| kontrastforhold | 1000:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193170% |
| responstid | 35 (Max.)(Tr+Td) |
| synsvinkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| lampe type | 10S1PWLEDWithout Driver |
| signal interface | MDDI/MIPI, 25 pins |
| indgangsspænding | 1.8/3.1V (Typ.)(IOVDD/AVDD) |
| Ansøgning | MPH |
