| Varenummer | AMS320FH01-0 |
| Mærke | Samsung |
| Størrelse | 3.2 |
| Ansøgning | MPH |
| Løsning | 240×400 |
| Sammensætning | OLED |
| Lysstyrke | 300 |
| CR | 10000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | self |
| Interface | MDDI |
| panel mærke | SAMSUNG |
| panel model | AMS320FH01-0 |
| paneltype | AM-OLED , OLED |
| panelstørrelse | 3.2 inch |
| løsning | 240(RGB)×400 , WQVGA |
| aktivt område | 41.76×69.6 mm |
| omrids | 46.16×76.58 mm |
| overflade | Glare (Haze 0%), Hard coating |
| lysstyrke | 300 cd/m² (Typ.) |
| kontrastforhold | 10000 : 1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE1931106% |
| synsvinkel | 60/60/60/60 (Min.)(CR≥200)(L/R/U/D) |
| signal interface | MDDI (1 data lane), 44 pins |
| indgangsspænding | 2.5/2.34/4.55/-5.0 (Typ.)(VCI/ADD3/ELVDD/ELVSS) |
| Ansøgning | MPH |
| AMS320FH01-0 | Samsung | 3.2 | 240×400 |
| H320QN01 V2 | AUO | 3.2 | 320×480 |
| H381DLN01.0 | AUO | 3.8 | 1080×1200 |
| HVA32WV1-D00 | HYDIS | 3.2 | 480×800 |
| LH350WS1-SD01 | LG Display | 3.5 | 640×960 |
| LH430WV1-SD01 | LG Display | 4.3 | 480×800 |
| LS030B3UW01 | SHARP | 3.0 | 240×400 |
| LS030Y3DX01 | SHARP | 3.0 | 480×800 |
| LS035Y8DX02A | SHARP | 3.5 | 480×800 |
| PJ055IA-14C | Innolux | 5.5 | 1080×1920 |
