| Varenummer | LH350H02-FD02 |
| Mærke | LG Display |
| Størrelse | 3.5 |
| Ansøgning | MPH |
| Løsning | 320×480 |
| Sammensætning | LCM |
| Lysstyrke | 450 |
| CR | 150:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | MIPI |
| panel mærke | LG Display |
| panel model | LH350H02-FD02 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 3.5 inch |
| løsning | 320(RGB)×480 , HVGA |
| visningstilstand | TN, Normally White, Transflective |
| aktivt område | 49.92×74.88 mm |
| omrids | 55.14×82.84×1.85 mm |
| overflade | |
| lysstyrke | 450 cd/m² (Typ.) |
| kontrastforhold | 150:1 (Typ.)(Transmissive)7:1 (Typ.)(Reflective) |
| vise farver | 16.7M (8-bit), CIE193150% |
| responstid | 30 (Typ.)(Tr+Td) |
| synsvinkel | 50/50/50/45 (Typ.)(CR≥10)(L/R/U/D) |
| lampe type | 6S1PWLEDWithout Driver |
| signal interface | MIPI (2 data lanes), 20 pins |
| indgangsspænding | 3.0/5.672/1.8V (Typ.)(VDDC/VDDA/LOVCC) |
| Ansøgning | MPH |
| LH350H01-FD01 | LG Display | 3.5 | 320×480 |
| LH350H01-FD01-A41 | LG Display | 3.5 | 320×480 |
| LH350H02-FD02 | LG Display | 3.5 | 320×480 |
| LMS350GF12-005 | Samsung | 3.5 | 320×240 |
| LQ035NC211 | Innolux | 3.5 | 320×240 |
| LQ035Q1DG04 | SHARP | 3.5 | 320×240 |
| LQ035Q3DG01 | SHARP | 3.5 | 320×240 |
| LQ035Q7DH05 | SHARP | 3.5 | 240×320 |
| NL2432HC22-40J | NLT | 3.5 | 240×320 |
| NL4864HL11-01B | NLT | 3.5 | 480×640 |
| ACX567AKM-7 | SONY | 3.2 | 320×480 |
| H497DAN01.0 | AUO | 5.0 | 1080×1920 |
| LQ034J1LX01 | SHARP | 3.4 | 320×480 |
| LS055R1SX04 | SHARP | 5.5 | 1440×2560 |
| LT031MDZ4000 | JDI | 3.1 | 720×720 |
| TD025THEB5 | TPO | 2.5 | 320×240 |
| TM018FDZ02 | Tianma | 1.8 | 128×160 |
| TM024HBZ26 | Tianma | 2.4 | 240×320 |
| TM035PDZ15 | Tianma | 3.5 | 320×480 |
| TX11D101VM0EAA | KOE | 4.3 | 480×800 |
