| Varenummer | B101EVT03.1 |
| Mærke | AUO |
| Størrelse | 10.1 |
| Ansøgning | PAD |
| Løsning | 1280×800 |
| Sammensætning | Assembly |
| Lysstyrke | 300 |
| CR | 1300:1 |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| panel mærke | AUO |
| panel model | B101EVT03.1 |
| paneltype | a-Si TFT-LCD , Assembly |
| panelstørrelse | 10.1 inch |
| løsning | 1280(RGB)×800 , WXGA |
| aktivt område | 216.96×135.6 mm |
| omrids | 253.15×167.75×6.7 mm |
| overflade | Antiglare |
| lysstyrke | 300 cd/m² (Typ.) |
| kontrastforhold | 1300:1 (Typ.) |
| vise farver | 262K (6-bit), CIE193147% |
| synsvinkel | 85/85/85/85 (Typ.)(CR＞10)(L/R/U/D) |
| frekvens | 60Hz |
| signal interface | LVDS (1 ch, 6-bit), 40 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | PAD |
