| Varenummer | BP070HD1-100 |
| Mærke | BOE |
| Størrelse | 7.0 |
| Ansøgning | PAD |
| Løsning | 720×1280 |
| Sammensætning | LCM |
| Lysstyrke | 450 |
| CR | 900:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | MIPI |
| panel mærke | BOE |
| panel model | BP070HD1-100 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 7.0 inch |
| løsning | 720(RGB)×1280 , WXGA |
| visningstilstand | PLS, Normally Black, Transmissive |
| aktivt område | 87.264×155.136 mm |
| omrids | 91.264×164.736 mm |
| overflade | Hard coating (2H) |
| lysstyrke | 450 cd/m² (Typ.) |
| kontrastforhold | 900:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193155% |
| responstid | 30 (Typ.)(Tr+Td) |
| synsvinkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 6S3PWLEDWithout Driver |
| signal interface | MIPI (4 data lanes), 34 pins |
| indgangsspænding | 1.8/3.3V (Typ.)(VCC/VDD) |
| Ansøgning | PAD |
