| Varenummer | B101XAN02.0 |
| Mærke | AUO |
| Størrelse | 10.1 |
| Ansøgning | PAD |
| Løsning | 1366×768 |
| Sammensætning | LCM |
| Lysstyrke | 250 |
| CR | 800:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | MIPI |
| panel mærke | AUO |
| panel model | B101XAN02.0 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 10.1 inch |
| løsning | 1366(RGB)×768 , WXGA |
| visningstilstand | AHVA, Normally Black, Transmissive |
| aktivt område | 222.341×125.568 mm |
| omrids | 235.01×138.95×4.7 mm |
| overflade | Glare (Haze 0%), Hard coating (3H) |
| lysstyrke | 250 cd/m² (Typ.) |
| kontrastforhold | 800:1 (Typ.) |
| vise farver | 16.7M (6-bit + Hi-FRC), CIE193150% |
| responstid | 15/10 (Typ.)(Tr/Td) |
| synsvinkel | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 4 stringsWLEDWithout Driver |
| signal interface | MIPI (4 data lanes), 39 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | PAD |
