| Varenummer | C0283QGLD-T |
| Mærke | CMEL |
| Størrelse | 2.8 |
| Ansøgning | MPH |
| Løsning | 240×320 |
| Sammensætning | OLED |
| Lysstyrke | 200 |
| CR | 10000:1 |
| Farver | 65K/262K |
| Baggrundsbelysning | self |
| Interface | CPU/RGB/SPI |
| panel mærke | CMEL |
| panel model | C0283QGLD-T |
| paneltype | AM-OLED , OLED |
| panelstørrelse | 2.8 inch |
| løsning | 240(RGB)×320 , QVGA |
| aktivt område | 43.2×57.6 mm |
| omrids | 49.1×67.3 mm |
| overflade | |
| lysstyrke | 200 cd/m² (Typ.) |
| kontrastforhold | 10000 : 1 (Typ.) |
| vise farver | 65K/262K , CIE193173% |
| synsvinkel | 85/85/85/85 (Typ.)(CR＞10)(L/R/U/D) |
| frekvens | 60Hz |
| driver ic | Built-in S6E63D6 |
| signal interface | 8/9/16/18-bit 6800/8080 parallel, 6/16/18-bit RGB, SPI, 61 pins |
| indgangsspænding | 2.8/1.8V (Typ.)(VCI/VDD3) |
| Ansøgning | MPH |
| AMCB004 | Samsung | 2.4 | 240×320 |
| LH430WV3-SH02 | LG Display | 4.3 | 480×800 |
| LPM055A138A | JDI | 5.5 | 1440×2560 |
| LQ050T1SX05(G) | SHARP | 5.0 | 1080×1920 |
| LS036Y1LX03 | SHARP | 3.6 | 480×800 |
| LS063K3SX01 | SHARP | 6.3 | 720×1280 |
| LT032MDQ7000 | JDI | 3.2 | 360×480 |
| LT044MDW7000 | TOSHIBA | 4.5 | 720×1280 |
| TM022GBH01 | Tianma | 2.2 | 176×220 |
| TM035PDZ00 | Tianma | 3.5 | 320×480 |
