| Varenummer | C043GW01 V0 |
| Mærke | AUO |
| Størrelse | 4.3 |
| Ansøgning | CNS |
| Løsning | 400×234 |
| Sammensætning | LCM |
| Lysstyrke | 600 |
| CR | 400:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | TTL |
| panel mærke | AUO |
| panel model | C043GW01 V0 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 4.3 inch |
| løsning | 400(RGB)×234 |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 94.8×52.65 mm |
| omrids | 107.7×65.6 mm |
| overflade | |
| lysstyrke | 600 cd/m² (Typ.) |
| kontrastforhold | 400:1 (Min.) |
| vise farver | 16.7M (8-bit) |
| responstid | 15/20 (Typ.)(Tr/Td) |
| synsvinkel | 60/60/40/60 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | WLED |
| signal interface | Parallel RGB (1 ch, 8-bit), 40 pins |
| indgangsspænding | 3.3V (Typ.)(VDD) |
| Ansøgning | CNS |
