| Varenummer | C080VW05 V0 |
| Mærke | AUO |
| Størrelse | 8.0 |
| Ansøgning | CNS |
| Løsning | 800×480 |
| Sammensætning | LCM |
| Lysstyrke | 500 |
| CR | 300:1 |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | TTL |
| panel mærke | AUO |
| panel model | C080VW05 V0 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 8.0 inch |
| løsning | 800(RGB)×480 , WVGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 175.2×105.12 mm |
| omrids | 186.5×117.22 mm |
| overflade | Antiglare |
| lysstyrke | 500 cd/m² (Typ.) |
| kontrastforhold | 300:1 (Typ.) |
| vise farver | 262K (6-bit) |
| responstid | 15/20 (Typ.)(Tr/Td) |
| synsvinkel | 60/60/40/60 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 4S4PWLEDWithout Driver |
| signal interface | Parallel RGB (1 ch, 6-bit), 60 pins |
| indgangsspænding | 3.3/10.0/15.0/-10.0V (Typ.)(VCC/AVDD/VGH/VGL) |
| Ansøgning | CNS |
| A080SN03 V3 | AUO | 8.0 | 800×600 |
| C080VW02 V0 | AUO | 8.0 | 800×480 |
| C080VW03 V0 | AUO | 8.0 | 800×480 |
| C080VW04 V0 | AUO | 8.0 | 800×480 |
| C080VW05 V0 | AUO | 8.0 | 800×480 |
| CLAA080WQ02 XN | CPT | 8.0 | 800×1280 |
| LB080WV6-TA03 | LG Display | 8.0 | 800×480 |
| LS800JT9001 | Innolux | 8.0 | 800×600 |
| TM080VG-22L01 | SANYO | 8.0 | 640×480 |
| TM080XPH01 | Tianma | 8.0 | 1280×768 |
| 70WVW1A | SII | 7.0 | 800×480 |
| C070VTN01.0 | AUO | 7.0 | 800×480 |
| C070VW04 V7 | AUO | 7.0 | 800×480 |
| CLAA070JA1BCW | CPT | 7.0 | 480×234 |
| HT07W12-200 | HYDIS | 7.0 | 480×234 |
| LB080WV6-TA03 | LG Display | 8.0 | 800×480 |
| LQ035Q5DG01 | SHARP | 3.5 | 320×240 |
| LQ064A5CG01 | SHARP | 6.4 | 480×234 |
| LQ065Y5DZ01 | SHARP | 6.5 | 800×480 |
| LTE052T-45 | Philips | 5.0 | 320×234 |
