| Varenummer | HT07W12-200 |
| Mærke | HYDIS |
| Størrelse | 7.0 |
| Ansøgning | CNS |
| Løsning | 480×234 |
| Sammensætning | LCM |
| Lysstyrke | 450 |
| CR | 250:1 |
| Farver | Full color |
| Baggrundsbelysning | CCFL |
| Interface | Analog |
| panel mærke | BOE HYDIS |
| panel model | HT07W12-200 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 7.0 inch |
| løsning | 480(RGB)×234 |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 154.08×87.05 mm |
| omrids | 167×102×12.5 mm |
| overflade | Antiglare, Hard coating |
| lysstyrke | 450 cd/m² (Typ.) |
| kontrastforhold | 250:1 (Typ.) |
| vise farver | Full color |
| responstid | 10/25 (Typ.)(Tr/Td) |
| synsvinkel | 60/60/40/50 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 1 pcsCCFLWithout Driver |
| signal interface | Analog RGB + Composite Video (NTSC/PAL), 30 pins |
| indgangsspænding | 9.0/5.0/18/-15/-10V (Typ.)(VCOM/VDD/VGH/VGL/VDL) |
| Ansøgning | CNS |
