| Varenummer | CLAA048LA0ACT |
| Mærke | CPT |
| Størrelse | 4.8 |
| Ansøgning | |
| Løsning | 800×480 |
| Sammensætning | LCM |
| Lysstyrke | 280 |
| CR | 400:1 |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| panel mærke | CPT |
| panel model | CLAA048LA0ACT |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 4.8 inch |
| løsning | 800(RGB)×480 , WVGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 103.8×62.28 mm |
| omrids | 114.65×74.7 mm |
| overflade | Glare (Haze 0%), Hard coating (3H) |
| lysstyrke | 280 cd/m² (Typ.) |
| kontrastforhold | 400:1 (Typ.) |
| vise farver | 262K (6-bit), CIE193148% |
| responstid | 20 (Typ.)(Tr+Td) |
| synsvinkel | 65/65/40/70 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | WLEDEmbedded (LED Driver) |
| signal interface | LVDS (1 ch, 6-bit), 30 pins |
| indgangsspænding | 3.3V (Typ.) |
