| Varenummer | LH480HX1-SD01 |
| Mærke | LG Display |
| Størrelse | 4.8 |
| Ansøgning | MPH |
| Løsning | 480×1024 |
| Sammensætning | LCM |
| Lysstyrke | 500 |
| CR | 700:1 |
| Farver | 16.2M |
| Baggrundsbelysning | WLED |
| Interface | TTL |
| panel mærke | LG Display |
| panel model | LH480HX1-SD01 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 4.8 inch |
| løsning | 480(RGB)×1024 |
| visningstilstand | IPS, Normally Black, Transmissive |
| aktivt område | 51.84×110.592 mm |
| omrids | 57.64×121.45 mm |
| overflade | |
| lysstyrke | 500 cd/m² (Typ.) |
| kontrastforhold | 700:1 (Typ.) |
| vise farver | 16.2M (6-bit + Dithering), CIE193168% |
| responstid | 35 (Typ.)(Tr+Td) |
| synsvinkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 5S2PWLEDWithout Driver |
| signal interface | Parallel RGB (1 ch, 8-bit) + SPI, 60 pins |
| indgangsspænding | 1.8/2.8V (Typ.)(IOVCC/VCC) |
