| Varenummer | P50AD4 |
| Mærke | E Ink |
| Størrelse | 5.0 |
| Ansøgning | |
| Løsning | 320×234 |
| Sammensætning | LCM |
| Lysstyrke | 320 |
| CR | 120:1 |
| Farver | Full color |
| Baggrundsbelysning | CCFL |
| Interface | Analog |
| panel mærke | PVI |
| panel model | P50AD4 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 5.0 inch |
| løsning | 320(RGB)×234 |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 102.6×73.9 mm |
| omrids | 126.9×92.7×13.2 mm |
| overflade | |
| lysstyrke | 320 cd/m² (Typ.) |
| kontrastforhold | 120:1 (Typ.) |
| vise farver | Full color |
| responstid | 30/50 (Max.)(Tr/Td) |
| synsvinkel | 55/55/15/35 (Typ.)(CR≥10)(L/R/U/D) |
| lampe type | 1 pcsCCFLWithout Driver |
| signal interface | Analog RGB, 20 pins |
| indgangsspænding | 5/14/20/-5V (Typ.)(VDD/VSH/VGH/VGL) |
