| Varenummer | LMS480JC01 |
| Mærke | Samsung |
| Størrelse | 4.8 |
| Ansøgning | PND |
| Løsning | 1024×600 |
| Sammensætning | LCM |
| Lysstyrke | 280 |
| CR | 350:1 |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| panel mærke | SAMSUNG |
| panel model | LMS480JC01 1 Compatible model |
| paneltype | LTPS TFT-LCD , LCM |
| panelstørrelse | 4.8 inch |
| løsning | 1024(RGB)×600 , WSVGA |
| visningstilstand | TN, Normally White, TMR |
| aktivt område | 104.45×61.2 mm |
| omrids | 112.05×73.26 mm |
| overflade | |
| lysstyrke | 280 cd/m² (Typ.) |
| kontrastforhold | 350 : 1 (Typ.) |
| vise farver | 262K (6-bit), CIE193150% |
| responstid | 28 (Typ.)(Tr+Td) |
| synsvinkel | 65/65/55/45 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 75Hz |
| lampe type | 5S1P+6S1PWLEDWithout Driver |
| signal interface | LVDS (1 ch, 6-bit), 28 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | PND |
