| Varenummer | CLAA100XA22XV |
| Mærke | CPT |
| Størrelse | 10.0 |
| Ansøgning | PAD |
| Løsning | 1024×768 |
| Sammensætning | LCM |
| Lysstyrke | |
| CR | 800:1 |
| Farver | 262K/16.2M |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| panel mærke | CPT |
| panel model | CLAA100XA22XV |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 10.0 inch |
| løsning | 1024(RGB)×768 , XGA |
| visningstilstand | HFFS, Normally Black, Transmissive |
| aktivt område | 202.752×152.064 mm |
| overflade | |
| lysstyrke | |
| kontrastforhold | 800:1 (Typ.) |
| vise farver | 262K/16.2M (6-bit / 6-bit + FRC), CIE193150% |
| responstid | 25 (Typ.)(Tr+Td) |
| synsvinkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | WLEDWithout Driver |
| signal interface | LVDS (1 ch, 6/8-bit), 40 pins |
| indgangsspænding | 3.3/13/18/-6V (Typ.)(VDD/AVDD/VGH/VGL) |
| Ansøgning | PAD |
