| Varenummer | CLAA102NA0DCW |
| Mærke | CPT |
| Størrelse | 10.2 |
| Ansøgning | CNS |
| Løsning | 1024×600 |
| Sammensætning | LCM |
| Lysstyrke | 400 |
| CR | 400:1 |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| panel mærke | CPT |
| panel model | CLAA102NA0DCW |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 10.2 inch |
| løsning | 1024(RGB)×600 , WSVGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 222.72×130.5 mm |
| omrids | 235×145.8×5.5 mm |
| overflade | Antiglare, Hard coating (3H) |
| lysstyrke | 400 cd/m² (Typ.) |
| kontrastforhold | 400:1 (Typ.) |
| vise farver | 262K (6-bit), CIE193150% |
| responstid | 20 (Typ.)(Tr+Td) |
| synsvinkel | 70/70/50/70 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | WLEDEmbedded (LED Driver) |
| signal interface | LVDS (1 ch, 6-bit), 30 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | CNS |
| CLAA100XA22XV | CPT | 10.0 | 1024×768 |
| CLAA101FP05 | CPT | 10.1 | 1920×1200 |
| CLAA101FP05 XG | CPT | 10.1 | 1920×1200 |
| CLAA101NC01CW | CPT | 10.1 | 1024×600 |
| CLAA101NC05 | CPT | 10.1 | 1024×600 |
| CLAA101ND06CW | CPT | 10.1 | 1024×600 |
| CLAA101WH12 LE | CPT | 10.1 | 1280×800 |
| CLAA101WJ03 XG | CPT | 10.1 | 1366×768 |
| CLAA101WJ06 | CPT | 10.1 | 1366×768 |
| CLAA104XA02CW | CPT | 10.4 | 1024×768 |
| C043FW01 V0 | AUO | 4.3 | 480×234 |
| C070VW01 V0 | AUO | 7.0 | 800×480 |
| CLAA050JA01CT | CPT | 5.0 | 480×272 |
| DLC0800AIG-2 | Other | 8.0 | 800×480 |
| L5F30947T0A | Epson | 6.5 | 800×480 |
| LA060N01-SD01 | LG Display | 6.0 | 720×272 |
| LA070WV1-TD03 | LG Display | 7.0 | 800×480 |
| LQ080Y5DW30 | SHARP | 8.0 | 800×480 |
| TJ123NP01AA | TPO | 12.3 | 1280×480 |
| YX050800480WTIPS | 5.0 | 800×480 |
