| Varenummer | CLAA101WJ03 XG |
| Mærke | CPT |
| Størrelse | 10.1 |
| Ansøgning | PAD |
| Løsning | 1366×768 |
| Sammensætning | LCM |
| Lysstyrke | 400 |
| CR | 600:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | MIPI |
| panel mærke | CPT |
| panel model | CLAA101WJ03 XG |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 10.1 inch |
| løsning | 1366(RGB)×768 , WXGA |
| visningstilstand | HFFS, Normally Black, Transmissive |
| aktivt område | 223.341×125.568 mm |
| omrids | 234.93×139.17×4.3 mm |
| overflade | Hard coating |
| lysstyrke | 400 cd/m² (Typ.) |
| kontrastforhold | 600:1 (Min.) |
| vise farver | 16.7M (8-bit), CIE193150% |
| responstid | 30 (Typ.)(Tr+Td) |
| synsvinkel | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 6S6PWLEDWithout Driver |
| signal interface | MIPI (4 data lanes), 39 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | PAD |
| CLAA101FP05 | CPT | 10.1 | 1920×1200 |
| CLAA101NC01CW | CPT | 10.1 | 1024×600 |
| CLAA101ND02CW | CPT | 10.1 | 1024×600 |
| CLAA101ND06CW | CPT | 10.1 | 1024×600 |
| CLAA101WA01 | CPT | 10.1 | 1366×768 |
| CLAA101WA01A | CPT | 10.1 | 1366×768 |
| CLAA101WJ01 | CPT | 10.1 | 1366×768 |
| CLAA101WJ02 | CPT | 10.1 | 1366×768 |
| CLAA101WJ03 XG | CPT | 10.1 | 1366×768 |
| CLAA101WJ06 | CPT | 10.1 | 1366×768 |
| CLAA070WP06G XG | CPT | 7.0 | 800×1280 |
| CLAA101FP01 XG | CPT | 10.1 | 1920×1200 |
| HT10X21-311 | HYDIS | 10.4 | 1024×768 |
| HT12X21-221 | HYDIS | 12.1 | 1024×768 |
| HV121WX5-121 | HYDIS | 12.1 | 1280×800 |
| HV121WX6-111 | HYDIS | 12.1 | 1280×800 |
| LQ101R1SX03 | SHARP | 10.1 | 2560×1600 |
| LQ104X2LX05B | SHARP | 10.4 | 1024×768 |
| TV101WUM-NH0 | BOE | 10.1 | 1200×1920 |
| VVX09F035M20 | Panasonic | 8.9 | 1920×1200 |
