| Varenummer | CLAA123PA02CW |
| Mærke | CPT |
| Størrelse | 12.3 |
| Ansøgning | Industrial Outdoor H |
| Løsning | 1440×540 |
| Sammensætning | a-Si TFT-LCD, LCM |
| Lysstyrke | |
| CR | 700:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| mærke | CPT |
| model | CLAA123PA02CW |
| diagonal størrelse | 12.3 inch |
| type | a-Si TFT-LCD, LCM |
| pixel format | 1440(RGB)×540 125PPI |
| konfiguration | RGB Vertical Stripe |
| aktivt område | 291.6(H)×109.35(V) mm |
| omrids dim. | 312.9(H)×132.2(V) ×19.2(D) mm |
| bezel område | 294.8(H)×112.4(V) mm |
| behandling | Antiglare (Haze 25%) |
| luminans | 800 cd/m² (Typ.) |
| kontrastforhold | 700:1 (Typ.) (TM) |
| visningsretning | 6 o'clock |
| responstid | 25 (Typ.)(Tr+Td) |
| synsvinkel | 60/60/50/60 (Typ.)(CR≥10) |
| driftstilstand | TN, Normally White, Transmissive |
| støtte farve | 16.7M 70% NTSC |
| lyskilde | WLED [8S3P] , 30K hours , W/O Driver |
| vægt | 510g (Typ.) |
| designet til | Industrial Outdoor High Brightness Automotive Display |
| billedhastighed | 60Hz |
| berøringspanel | Without |
| interface type | LVDS (1 ch, 8-bit) , 30 pins Connector |
| Strømforsyning | 3.3V (Typ.) |
| miljø | Operating Temperature: -40 ~ 85 °C ; Storage Temperature: -40 ~ 90 °C ; Vibration Level: 2.9G (28.4 m/s²) |
