| Varenummer | DLC0283FZG-7 |
| Mærke | Other |
| Størrelse | 2.8 |
| Ansøgning | MPH |
| Løsning | 240×320 |
| Sammensætning | LCM |
| Lysstyrke | 300 |
| CR | 400:1 |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | CPU/RGB |
| panel mærke | DLC |
| panel model | DLC0283FZG-7 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 2.8 inch |
| løsning | 240(RGB)×320 , QVGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 43.2×57.6 mm |
| omrids | 50×70 mm |
| overflade | |
| lysstyrke | 300 cd/m² (Typ.) |
| kontrastforhold | 400:1 (Typ.) |
| vise farver | 262K , CIE193150% |
| responstid | 25 (Typ.)(Tr+Td) |
| synsvinkel | 60/60/60/45 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 5S1PWLEDWithout Driver |
| signal interface | CPU/RGB, 39 pins |
| indgangsspænding | 1.8/2.8V (Typ.)(IOVCC/VCC) |
| Ansøgning | MPH |
