| Varenummer | H380VW01 V2 |
| Mærke | AUO |
| Størrelse | 3.8 |
| Ansøgning | MPH |
| Løsning | 480×800 |
| Sammensætning | LCM |
| Lysstyrke | 450 |
| CR | 700:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | TTL |
| panel mærke | AUO |
| panel model | H380VW01 V2 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 3.8 inch |
| løsning | 480(RGB)×800 , WVGA |
| visningstilstand | AHVA, Normally Black, Transmissive |
| aktivt område | 49.68×82.8 mm |
| omrids | 53.94×116.49 mm |
| overflade | |
| lysstyrke | 450 cd/m² (Typ.) |
| kontrastforhold | 700:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193170% |
| responstid | 20/15 (Typ.)(Tr/Td) |
| synsvinkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 4S2PWLEDWithout Driver |
| signal interface | Parallel RGB (1 ch, 8-bit) + SPI, 60 pins |
| indgangsspænding | 1.8/3.0V (Typ.)(IOVDD/AVDD) |
| Ansøgning | MPH |
| CMD510TT00-C1 | ORTUSTECH | 3.8 | 320×240 |
| H380VW01 V2 | AUO | 3.8 | 480×800 |
| KCS038AA1AG-G21 | Kyocera | 3.8 | 240×320 |
| LQ038B3DD01 | SHARP | 3.8 | 320×480 |
| LQ038Q7DB03 | SHARP | 3.8 | 240×320 |
| LS038Y7DX01 | SHARP | 3.8 | 480×800 |
| SP10Q010 | KOE | 3.8 | 320×240 |
| TM038QV-67A02E | SANYO | 3.8 | 320×240 |
| TM038QV-67A03 | SANYO | 3.8 | 320×240 |
| AMCB004 | Samsung | 2.4 | 240×320 |
| AMS410GJ02-0 | Samsung | 4.1 | 480×800 |
| AMS465GS53 | Samsung | 4.7 | 720×1280 |
| DLC0220KZG | Other | 2.2 | 320×320 |
| H381DLN01.0 | AUO | 3.8 | 1080×1200 |
| LH400WV3-SD04 | LG Display | 4.0 | 480×800 |
| LH470WX6-SD02 | LG Display | 4.7 | 750×1334 |
| LH530QH1-SD01 | LG Display | 5.3 | 1440×2560 |
| TM022HDHT1-05 | Tianma | 2.2 | 240×320 |
| TX06D15VM1EAA | KOE | 2.2 | 176×220 |
