| Varenummer | LMS283GF11 |
| Mærke | Samsung |
| Størrelse | 2.8 |
| Ansøgning | MPH |
| Løsning | 240×320 |
| Sammensætning | LCM |
| Lysstyrke | 330 |
| CR | 290:1 |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | CPU |
| panel mærke | SAMSUNG |
| panel model | LMS283GF11 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 2.8 inch |
| løsning | 240(RGB)×320 , QVGA |
| visningstilstand | TN, Normally White, TMR |
| aktivt område | 43.2×57.6 mm |
| omrids | 50×69.2 mm |
| overflade | |
| lysstyrke | 330 cd/m² (Typ.) |
| kontrastforhold | 290 : 1 (Typ.) |
| vise farver | 262K (6-bit), CIE193160% |
| responstid | 35 (Typ.)(Tr+Td) |
| synsvinkel | 50/50/50/20 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 1S4PWLEDWithout Driver |
| signal interface | CPU, 40 pins |
| indgangsspænding | 1.8/2.8V (Typ.)(VCC/VCI) |
| Ansøgning | MPH |
