| Varenummer | CLAF055WB41 TXX |
| Mærke | CPT |
| Størrelse | 5.5 |
| Ansøgning | MPH |
| Løsning | 720×1280 |
| Sammensætning | CELL |
| Lysstyrke | 0 |
| CR | 800:1 |
| Farver | |
| Baggrundsbelysning | No B/L |
| Interface | |
| panel mærke | CPT |
| panel model | CLAF055WB41 TXX 2 Compatible model |
| paneltype | a-Si TFT-LCD , CELL |
| panelstørrelse | 5.5 inch |
| løsning | 720(RGB)×1280 , WXGA |
| visningstilstand | HFFS, Normally Black, Transmissive |
| aktivt område | 68.04×120.96 mm |
| omrids | 70.44×128.56 mm |
| overflade | Hard coating |
| glas dybde | 0.20+0.20 mm |
| transmissivitet | 5.0% (Typ.)(with APCF) |
| kontrastforhold | 800:1 (Typ.) |
| vise farver | , CIE193170% |
| responstid | 30 (Typ.)(Tr+Td) |
| synsvinkel | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| driver ic | Suggest ILI9881, OTM1284A-C1 |
| Ansøgning | MPH |
| ACX567AKM-7 | SONY | 3.2 | 320×480 |
| AMS320FS03 | Samsung | 3.2 | 320×480 |
| AMS347FF01 | Samsung | 3.5 | 360×640 |
| DLC0283FZG-7 | Other | 2.8 | 240×320 |
| LQ024B7UD01 | SHARP | 2.4 | 160×240 |
| LS038Y7DX01 | SHARP | 3.8 | 480×800 |
| LT032MDQ7000 | JDI | 3.2 | 360×480 |
| PJ035MA-02A | Innolux | 3.5 | 320×480 |
| TD028STEB2 | TPO | 2.8 | 240×320 |
| TM055XDHP10 | Tianma | 5.5 | 540×960 |
