| Varenummer | TM055XDHP10 |
| Mærke | Tianma |
| Størrelse | 5.5 |
| Ansøgning | MPH |
| Løsning | 540×960 |
| Sammensætning | LCM |
| Lysstyrke | 350 |
| CR | 800:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | MIPI |
| panel mærke | TIANMA |
| panel model | TM055XDHP10 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 5.5 inch |
| løsning | 540(RGB)×960 , qHD |
| visningstilstand | FFS, Normally Black, Transmissive |
| aktivt område | 68.04×120.96 mm |
| omrids | 72.14×130.86×1.95 mm |
| overflade | Antiglare (Haze 42%) |
| lysstyrke | 350 cd/m² (Typ.) |
| kontrastforhold | 800:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193170% |
| responstid | 25 (Typ.)(Tr+Td) |
| synsvinkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 80Hz |
| lampe type | 5S2PWLEDWithout Driver |
| signal interface | MIPI (2 data lanes), 30 pins |
| indgangsspænding | 1.8/2.8V (Typ.)(IOVCC/VCC) |
| Ansøgning | MPH |
